Standard Equipment
UV curring system, IR curring system, hot air curring system.
Full sets of chrome plated precision ground printing cylinders
complete with gears and plate mounting guides.
1x magnetic cylinder.
1x video printing inspection system (with camera, monitor, sensor)
1 x printing plate mounter.
1 x Toolbox.
Technical Specification:
| Printing speed: | 5-100m/min |
| Printing colour: | 1-10 colours |
| Printing length: | 175-380mm |
| Max. web width: | 330mm |
| Max. printing width: | 320mm |
| Max. unwinding diameter: | 600mm or 1000mm |
| Max. rewinding diameter: | 600mm |
| Waste matrix diameter: | 600mm |
| Print register tolerance: | +/- 0.01 |
| Main machine size: | 3500mm x 1100mm x 3000mm (LxWxH) |
| Voltage: | 380V |
3 DIE CUTTING STATIONS
ROLL ROLL- ROLL TO SHEET
Standard Specification:
- Inflatable 3″ unwind shaft.
- Side lay adjuster to unwind shaft.
- Electronically controlled magnetic powder brake system for the unwind.
- End off roll stop.
- Web Edge Guide using 2 x web edge scanners for accuracy.
- Splicing table with paper clamps.
- Precision ground nip roller.
- Mitsubishi in-feed system.
- Constant turning ceramic anilox roller.
- Anilox drop off prior to stopping to clean printing plate.
- Pneumatic Printing cylinder auto throw off.
- Quick change ceramic anilox rollers.
- Quick change rubber metering rollers.
- Reverse angle self adjusting doctor blade.
- Ink pan with outlet for ink pumping system.
- 360° lateral register adjustment.
- Longitudinal register adjustment.
- Single pneumatically inflated 3″ rewind shaft.
- Electronically controlled magnetic powder clutch system
- for the rewind.
- Linear meter counter.
- Pneumatic inflator gun and hose.
